Valve F69Q3 Automatic Softener Valve (up to 2 m³/h)

⚙️ Runxin F69Q3 — Automatic Softener Valve (up to 2 m³/h)

Application

Runxin F69Q3 is an automatic multi-function valve designed for managing residential and small commercial water softening systems. It supports all core regeneration stages and allows reliable and efficient water treatment operation.

⚙️ Key Features

✅ 5 operating modes: filtration, backwash, regeneration, rinse, brine tank refill
✅ Top-mount installation (2.5" thread)
✅ Programmable by time or water consumption
✅ Long-lasting ceramic seal
✅ User-friendly control interface with compact design

⚙️ Technical Specifications

• Flow rate: up to 2 m³/h

• Inlet/outlet: 3/4" (female thread)

• Drain: 1/2" (male thread)

• Brine line: 3/8" (male thread)

• Operating pressure: 0.15–0.6 MPa

• Temperature: +5°C to +50°C

• Power supply: 100–240 V / 50–60 Hz

• Compatible tank size: 6" to 12"

Package Includes

✔️ Runxin F69Q3 valve
✔️ Connection fittings
✔️ User manual
