Characteristics
- Self-priming and frequency controlled, based on the Badu Compact model.
- Connection sizes similar to Badu Magic and Alpha series, interchangeable.
- Hydraulically optimized for small (above-ground) swimming pools, extremely energy efficient.
- Transparent lid and pre-filter 0.5 litre.
- 3 freely adjustable speeds. Both the speed and the stop function can be controlled externally via potential-free contacts.
- The electrical part is completely galvanically isolated.
- Can be placed a maximum of 2 meters above or 3 meters below water level.
- Applicable in combination with salt electrolysis systems with a salt concentration of 0.5% (5 grams/litre).
- Equipped with 5-wire cable for external control of speed and stop function via potential-free contacts.
| PPG Compact Eco Soft | |
| Capacity in m³/h (at 8 mwc/3000 rpm) | 15 |
| Power in kW (at 3000 rpm | |
| - included (P1) | 0,75 |
| - issued (P2) | 0.50 |
| HP | 0,75 |
| Voltage | 230 |
| Current in Amps (at 3000 rpm) | 3.2(max) |
| Suction/discharge connection size (glue) | 50F/50F |
| Weight in kg | 7 |
